Dassault Systemes 3DVia Composer v6R2011x HF4 v6.7.4.1574

Posted By: Artist14
Dassault Systemes 3DVia Composer v6R2011x HF4 v6.7.4.1574

Dassault Systemes 3DVia Composer v6R2011x HF4 v6.7.4.1574 | 402 MB

3DVIA Composer is a desktop application for revolutionizing the creation of product deliverables. Animations including kinematics and reverse-kinematics, as well as high-resolution raster images including BMP, JPG, PNG, and TIF files, can be created easily. Producing 2D line art as SVG and CGM files is quick and easy with 3DVIA Composer’s built-in technical illustration capabilities. Product information stored in ENOVIA systems can be directly accessed using the power of ENOVIA 3DLive. 3DVIA Composer users can easily and visually navigate and filter the exact 3D product configuration stored in ENOVIA, and use it to create and update their 3DVIA Composer documentation projects. 3DVIA Composer allows users to control and manage access to their intellectual property in 3DVIA Composer-generated deliverables. With "Right Manager" settings, content creators can manage access control when playing content with 3DVIA Composer Player and can also use patented "Secure3D" technology to prevent copying or theft of the intellectual property.

3DVIA Composer V6R2011x offers a robust collection of enhancements in several key areas:

Global Collaborative Innovation

Unicode: Developing and deploying 3DVIA Composer content to global au-diences has become easier with the addition of Unicode character encoding in V6R2011x. Unicode allows for more consistent representation and handling of in-ternational writing systems, providing users with a significant advantage when content must be localized for delivery across the globe.

Dassault Systemes 3DVia Composer v6R2011x HF4 v6.7.4.1574

Lifelike Experience
Ambient Occlusion: Ambient occlusion adds another level of realism to your 3D renderings by taking into account the attenuation of light due to occlusion. Using this method gives your renderings a softer and more natural appearance.

Dassault Systemes 3DVia Composer v6R2011x HF4 v6.7.4.1574

Per-Pixel lighting: Also known as Phong shading, per-pixel lighting lets you dif-fuse the reflection of light on your model surfaces, improving the interpolation of light and adding additional realism to your 3DVIA Composer renderings.

Dassault Systemes 3DVia Composer v6R2011x HF4 v6.7.4.1574

Depth of Field: The new depth of field functionality allows you to blur portions of the screen away from the camera focal point. With this you can better draw focus to specific geometry actors, while deemphasizing elements of the background.

Dassault Systemes 3DVia Composer v6R2011x HF4 v6.7.4.1574

Alpha Channels: The addition of alpha channels in 3DVIA Composer V6R2011x helps improve your raster images to be better than ever. Using alpha channels lets you to control the transparency of a raster image, so you can more smoothly blend images with the background. This gives your images a whole new level of visual appeal, allowing you to even more clearly communicate your design details.

Dassault Systemes 3DVia Composer v6R2011x HF4 v6.7.4.1574

Layered Rendering: The new layered rendering feature in the technical illustration workshop allows layers to be custom defined and prioritized in vector graphic output. This enables line styles to be defined by layer for clear definition of hid-den assembly components in technical illustrations. Traditionally this process has been a manual and time consuming process. Now with 3DVIA Composer V6R2011x, it’s a snap.

Dassault Systemes 3DVia Composer v6R2011x HF4 v6.7.4.1574

Custom Hotspots: Hotspots are groups of actors, with a shared highlight, tool-tip, and link properties that help more clearly define custom sets of actors in vector output. Now in 3DVIA Composer V6R2011x you can define custom hotspots and include them in vector output – to help create an even richer in-teractive experience. Additionally, bill of Material hotspots can now be gener-ated for either CGM or SVG output formats.

Dassault Systemes 3DVia Composer v6R2011x HF4 v6.7.4.1574

Silhouettes: The new Silhouette method options let you choose from three differ-ent silhouette styles. Crest generates silhouettes for actor perimeters and signifi-cant actor edges. Per Actor generates silhouettes for actor perimeters. And the Model method generates silhouettes for perimeters around contiguous actors.

Customizable Compass: To make it even easier to navigate around 3DVIA Com-poser applications, a new customizable compass has been added. Previously the compass would only display the position of actors in relation to their X, Y, and Z axis. Now you can choose to configure the compass just like a collaborative actor. Not only does this make your applications more visually appealing, but it also helps to better visualize the orientation of the geometry being displayed.

Dassault Systemes 3DVia Composer v6R2011x HF4 v6.7.4.1574
