Autodesk AutoCAD Electrical 2018.1.1

Posted By: scutter
Autodesk AutoCAD Electrical 2018.1.1

Autodesk AutoCAD Electrical 2018.1.1 | 5.7 Gb

Autodesk Inc., a world leader in 3D design software for entertainment, natural resources, manufacturing, engineering, construction, and civil infrastructure, announced the release of Autocad Electrical 2018.1.1, part of the Autodesk solution for Digital Prototyping, is AutoCAD software for controls designers, purpose-built to create and modify electrical control systems.

- Xref Layer Property Enhancements
To provide more flexibility for controlling xref overrides, the Layer Settings dialog box, which is accessed from the Layer Properties Manager, includes new controls for managing Xref layer properties. When the option to retain overrides to xref layer properties is turned on with the VISRETAIN system variable, you can now specify which xref layer properties that you want to reload. The various layer property options are stored in the registry as specified by the new VISRETAINMODE system variable. The Layer Properties Manager also includes a new status icon to indicate when a layer associated with an xref includes overrides.
Primary commands and system variables: LAYER, VISRETAIN, VISRETAINMODE, XREFOVERRIDE
- Views and Viewports
You can now easily create, retrieve, and place model views together with automatically sized and scaled layout viewports onto the current layout. When selected, layout viewport objects display two additional grips, one for moving the viewport, and the other for setting the display scale from a list of commonly used scales.
Primary commands and system variables: MVIEW, NEWVIEW
- High resolution (4K) monitor support
Support for high resolution monitors continues to be improved in the Update. More than 200 dialog boxes and other User Interface elements have been updated to ensure a quality viewing experience on high-resolution (4K) displays.
For the best results, use the Windows 10 operating system and a compatible video card
- 3D Graphics Performance
The 3D graphics performance for the Wireframe, Realistic, and Shaded visual styles continues to increase depending on the content of the DWG files tested. For example, the median value for the frames-per-second performance in the six large benchmark models used increased by 37% in the Update as compared to AutoCAD 2018.
Primary commands and system variables: 3DORBIT, ZOOM, PAN, VSCURRENT

Problems Reported Through the Customer Error Reporting Utility

As a result of the detailed information that we received from customers who used the Customer Error Reporting Utility, we were able to identify and fix several defects with the following results:

- Occasional crashes when opening the block editor no longer occur.
- Occasional crashes when selecting or creating a non-associative hatch no longer occur.
- Occasional crashes when clicking the Insert View button on the ribbon in some drawings no longer occur.
- Occasional crashes when modifying certain dimension styles no longer occur.
- Occasional crashes when editing the grip of a spotlight in some drawings no longer occur.
- Occasional crashes when opening DXF files containing Xrefs no longer occur.

General Update Content

Several additional defects have been fixed with the following results:

Blocks
- The attribute position of a block remains the same after editing the block.
PDF/Plot
- PDF files plotted from certain drawings now display correctly in Adobe Reader.
- Hatch patterns in PDF files are consistent with lineweight.
- Raster images are plotted correctly when Shadeplot is set to the Rendered option.
General
- The AEC property-set data in DWG files can be successfully exported to 3D DWF files.
- Certain Pro/E files can now be successfully imported into AutoCAD.

- Произведено объединение четырех оригинальных дистрибутивов в один: английский х64, английский х86, русский х64, русский х86.
- В инсталлер добавлена возможность установки локальной справки как для английской, так и для русской версии программы.
- В инсталлер добавлена возможность установки модуля поддержки VBA-макросов.
- В инсталлер добавлена возможность установки модуля SPDS Extension 6.0 позволяющего оформлять чертежи согласно требованиям ГОСТ 21.1101-2009.
- В инсталлер добавлена возможность установки модуля BIM 360 Glue 4.70.6.
- Добавлена возможность подключения "классического интерфейса"
- В установочный пакет AutoCAD Electrical 2018 произведена интеграция AutoCAD 2018.1.1 Update.
- Установочный пакет Autodesk Recap 2018 обновлен с версии 4.0.0.28 до версии 4.2.1.7.
- Утилита Autodesk Desktop App обновлена с версии 7.0.4.332 до версии 7.0.6.378.
- Утилита Autodesk Licensing Manager обновлена с версии 5.1.4 до версии 5.1.5 HotFix 1.
- Используемый в оригинальных дистрибутивах пакет .NET Framework 4.6 заменен на переработанный вариант из проекта [Slim] .NET Framework 4.7 Full x86/x64, со встроенными обновлениями по состоянию на 23 июля 2017 года.
- Добавлена возможность отказа от установки утилиты Autodesk Desktop App.

Autodesk AutoCAD Electrical 2018.1.1

О Autodesk Autocad Electrical. AutoCAD Electrical — это AutoCAD для проектирования электрических систем управления, являющийся важной частью технологии цифровых прототипов Autodesk и позволяющий работать быстро, качественно и со значительно меньшими затратами в знакомой среде проектирования. Специализированные функции и обширные библиотеки условных обозначений позволяют повысить производительность, устранить риск возникновения ошибок и обеспечить точность информации, передаваемой в производство.

About Autodesk Autocad Electrical. AutoCAD electrical 2018 design software helps electrical engineers and detailers drive control system design productivity to previously unachievable levels with specialised electrical design functionality and toolsets geared to electrical control system design requirements.

About Autodesk. Autodesk helps people imagine, design and create a better world. Everyone—from design professionals, engineers and architects to digital artists, students and hobbyists—uses Autodesk software to unlock their creativity and solve important challenges.

Product: Autodesk Autocad Electrical
Version: 2018 Build 15.0.50.0 (2018.1.1 Build O.154.0.0)
Supported Architectures: 32bit / 64bit
Website Home Page : www.autodesk.com
Language: english, russian
System Requirements: PC
Supported Operating Systems: Windows 7even / 8.x / 10
Size: 5.7 Gb
