CAMWorks 2022 SP2 for Solid Edge

1. CW-116304 CSR-20910 TechDB In Turn mode, when you right click on any Turn feature in the feature tree and select parameters to view the Feature Parameters dialog box, by clicking on the TechDB ID on the strategy drop-down list launches TechDB application and displays the features and operations. However, data for the wrong TechDB ID is getting displayed.
2. CWR-2054 –– Toolpath When the 3 Axis Mill Toolpath generation method is set to ‘Advanced’, the Offset Curve option 'Contain only' for Constant Stepover operations behaves like "Contain and Avoid", resulting in incorrect toolpaths.
3. CWR-2048 CSR-20603 Toolpath When the 3 Axis Mill Toolpath generation method is set to ‘Advanced’, for the specific part’s Area Clearance toolpath, the tool diameter is 100% engaged in the 'Area Clearance' 'Pocket In Core' pattern due to incorrectly considering the stock geometry with XY stepover.
4. CWR-2044 CSR-20516 Toolpath When the 3 Axis Mill Toolpath generation method is set to ‘Advanced’ and the toolpath is generated for the specific part using Lace Pattern, the resultant toolpath has inconsistent behavior for entry moves.
5. CW-115397 CSR-20495 TechDB When customized TechDB is used in Metric mode and user navigates to User Defined Tools within the Mill Tooling menu, the concerned user interface fails to launch.
6. CW-115356 CSR-20392 User Interface In Assembly mode, for any operation when the holder is changed from ‘user defined’ to ‘basic’, the holder information gets updated, but the corresponding image and the model does not get updated and remains as ‘User defined’ only.
7. CW-115309 CSR-20399 Simulation When using Fixture Avoidance with “Avoid All” option is used for the Contour Mill toolpath of the specific Mill part, the NC code crashes but the Contour Mil toolpath move causing the crash is not visible when executing Simulation.
8. CWR-2038 CSR-20355 Toolpath When the 3 Axis Mill Toolpath generation method is set to ‘Advanced’ and a Pattern Project toolpath is generated for a filleted surface of a specific mill part, the resultant toolpath is making an incorrect liner link move from the vertical feature edge geometry
9. CWR-2033 CSR-20153 Toolpath When the 3 Axis Mill Toolpath generation method is set to ‘Advanced’ and a Z Level toolpath is generated for a specific part using a tool with tapered non-cutting portion, a poor quality toolpath is generated. Increasing the toolpath length amount causes more cycle time. This issue was not present in CAMWorks For Solid Edge 2019 version.
10. CWR-2031 CSR-20136 Toolpath When the 3 Axis Mill Toolpath generation method is set to ‘Advanced’ and a Z Level toolpath is generated for the specific part using Ramp linking type, the link moves move off the feature surface and tool contact is lost.
11. CW-115089 CSR-20157 Post In Mill Assembly mode, when stock of type "Pre-definedBounding Box" is selected, the variables "STOCK_MIN" and "STOCK_MAX" does not output the correct coordinates in posted NC code as per the Coordinate System selected.
12. CW-115062 CW-113036 CSR-20250 CSR-19123 VoluMill For the specific Mill part, the VoluMill toolpath generated contains an unnecessary secondary pass.
13. CW-115032 CSR-20055 TechDB When the specific user-defined TechDB linked to CAMWorks for Solid Edge 2022 version is opened, the TechDB does not list the MC (Metric Coarse) and MF(Metric Fine) Thread Mill definitions properly in the concerned user interface.
14. CW-115028 CSR-20163 Post In CAMWorks For Solid Edge 2022, when a post operation is inserted by right mouse click of a setup, then it is inserted after the last available operation in the operation tree.
15. CW-115000 CSR-20093 Toolpath For the specific Mill-Turn part, the Link move of its Area Clearance toolpath runs through uncut stock with no control available for retracting in Z. This is happening due to presence of an unnecessary feed move.
16. CWR-2026 CSR-19943 Toolpath In Mill mode, when Z Level toolpaths are generated using the Advanced Method, if the cut type for Z level toolpath is changed to ‘helical’, then it still uses the horizontal arc parameters for calculating toolpath moves though they are not supported for the helical cut type.
17. CW-114948 CSR-20068 Toolpath For the specific Mill part, the Contour Mill toolpath gouges the part on the finish side passes when “Single cut depth” option is checked with “Spring pass” option selected at the side parameter. Gouging is observed at the Lead in.
18. CW-114947 CSR-10230 Toolpath For the specific part containing a slot feature with chamfer, the contour mill toolpath generated gouges the part on finish side passes when “Single cut depth” option is checked at the side parameter. The gouge occurs at lead in.
19. CW-114929 CSR-20051 Toolpath The ‘Optimize Between Groups’ option fails to function correctly resulting in repetitive machining of the features.
20. CW-114791 CSR-19952 Post For Multiaxis machining operations, the variables MCS_X_OFFSET, MCS_Y_OFFSET and MCS_Z_OFFSET returns "zero" value when posted.
21. CW-114784 CSR-19939 Post When post header FACE_ARC is set to BOTH then for some face free toolpaths with arcs, the post variable CURRENT_SYSTEM changes to -1 from 512.
22. CW-114691 CSR-19927 Toolpath For any mill part, when the retract point is selected (Arc Centre or point) for Contour Mill toolpath with Ramp option checked then it generates incorrect toolpath. The toolpath makes angular move downwards to the setup XY plane and then retract in Z direction.
23. CW-114623 CSR-19886 TechDB In the customized TechDB, the Default Operation Parameters User Interface Page for Probing tool is blank in Inch mode.
24. CW-114608 CSR-19855 Rebuild For the specific assembly, the Fixture Coordinate System assigned by the user is incorrectly located and doesn’t get reset even after multiple Rebuild attempts.
25. CW-114584 CSR-19841 Feature When the ‘Engrave feature’ option is selected for Contour Mill operation, the ‘Zigzag’ option within Depth processing group box is grayed out. However, when the Rest machining option is changed from ‘None’ to ‘Previous tool’ and back to ‘None’, then the ‘Zigzag’ option gets activated. This is unexpected behavior.
26. CW-114583 CSR-19839 Operation For Multiaxis mill operation, under Links tab, if you switch from % (Percentage) to mm for the Links threshold parameter, then it displays a value computed on the basis of 50% of the tool diameter instead of 50% of the max stepover.
27. CW-114564 CSR-19826 Rebuild For any 2.5 axis Mill part, when any hole group feature is created, if the option is changed to Through in Hole Parameters dialog box and then if rebuild is executed the group feature dissolves.
28. CW-114551 CSR-18414 TechDB In the Technology Database shipped along with CAMWorks For Solid Edge, the Tap-Cutting Strategies for Threading under Mill Tooling, must support Sub-Spindle setup strategies. Currently, they are not supported.
29. CW-114550 CSR-19008 TechDB The parameter “Over Allowance” (negative value input) was renamed to “Min Stock to remove” (positive value input) within the application. This change also needs to be implemented in TechDB.
30. CW-114526 CSR-19798 Toolpath Toolpath creates gouge in Rough Passes when Contour Mill Single Depth cut check box is selected.
31. CW-114515 CSR-19755 Translation In Japanese language version of CAMWorks For Solid Edge, some of the Japanese text strings under the Feed/Speed tab needs to be modified as they are incorrectly translated. They need to be translated in corresponding TechDB UI as well.
32. CW-114492 CSR-19762 Rebuild For specific programmed part, the toolpath for Hole group feature doesn't get updated after unsuppressing one of the solid bodies and executing the Rebuild command.
33. CW-114491 CSR-19754 UI When selecting the "Toolpath center" radio button on the "NC" tab of the contour mill, the parameter images of the NC tab user interface do not change.
34. CW-114487 CSR-19746 Translation In Japanese language version of CAMWorks For Solid Edge, the English string 'Barrel tooling' need to be localized at three locations within the user interface.
35. CW-114468 CSR-19713 Translation In the Chinese Traditional language version of CAMWorksFor Solid Edge, the string named ‘Retract Dist’ under the NC tab of Operation Parameters dialog box is missing.
36. CW-114437 CSR-19729 Feature The Curve Feature with the 'edge break' strategy for chamfering by the EMF is incorrect. The Feature is correct if added manually.
37. CW-114333 CSR-5970 UI If the Replace tool option is used in Tool tree tab with assembly tool crib then after selecting the Ok command on Tool Select Filter dialogue box it again opens a new dialogue box listing all the assembly tools which is not necessary.
38. CW-114310 CSR-19615 Translation In Czech language version of CAMWorks For Solid Edge, in Turn module, some of the Czech language text stringsunder Tool tab UI need to be updated.
39. CWR-2021 CSR-19612 Toolpath For the specific Assembly file, color settings have been assigned CAMWorks Options UI for 3 Axis Finish toolpath moves (yellow) and Link moves (green). On generating Z Level toolpath with zigzag pattern, it is observed that the finish moves are displayed in green (instead of yellow) as it considers those moves as link moves.
40. CWR-2020 CSR-19596 Toolpath In Mill mode, whenever any Area Clearance toolpath (for which an Automatic Contain Area with Method set to “All Silhouettes” has been assigned) is generated using ‘Advanced’ method of 3 Axis Mill toolpath generation, it is observed that the toolpath gets generated beyond the Contain Area.
41. CW-114217 CSR-19521 Operation The face milling operation for the specific Mill part with automatic angle, changes the direction of cut along with an error message. This happens only when the avoid area is applied.
42. CW-114181 CSR-19541 Feature For any Mill part, the lines within the pocket features are not automatically added when shift keys are used to add the feature.
43. CWR-2016 CSR-19516 Toolpath When the 3 Axis Mill Toolpath generation method is set to ‘Advanced’ and the Area Clearance operation is generated for the specific Mill part, it is observed that its toolpath has a retract move with excess height that doesn’t consider the applied parameter value during the toolpath link. This occurs even though the Method is set to “Skim”.
44. CWR-2015 CSR-19501 Toolpath When the 3 Axis Mill Toolpath generation method is set to ‘Advanced’ and a Slice Pattern toolpath is generated for the specific Mill Assembly, it is observed that the toolpath doesn’t apply uniform scallop distance for the XY stepover.
45. CWR-2014 CSR-19471 Toolpath When the 3 Axis Mill Toolpath generation method is set to ‘Advanced’ and toolpaths are generated for three identical operations differing only in Machine Deviation for a specific Mill Assembly, one of the toolpaths fails to generate. The toolpath for the operation with Mach. Deviation 0.001 does not get generated and an ‘Error 105’ message is displayed.
46. CWR-2011 CSR-19356 Toolpath When the 3 Axis Mill Toolpath generation method is set to ‘Advanced’ and a 3D Stepover Flowline Pattern Project toolpath is generated for the specific Mill part, it is observed that the toolpath misses many passes, which is not optimal machining.
47. CW-113786 CSR-10496 TechDB The assembly tools do not get replaced when any tool is selected from the TechDB.
48. CW-113779 CSR-17682 Assembly For any Assembly part, the "Insert Mill Part Setup" option cannot be selected for the second Feature Manager.
49. CW-113778 CSR-19439 Toolpath In Turn mode, when the depth of an ID feature is changed and the part is Rebuilt, the Drill cycles are not updated to reflect the updated feature depth.
50. CW-113733 CSR-19387 Toolpath For the specific part, when Step Through is executed for the Offset Roughing toolpath, it is observed that the toolpath repeatedly makes cuts in the same place.
51. CW-113489 CSR-19308 Translation In the Spanish language version of CAMWorks For Solid Edge, some of the Spanish strings under the Geometry tab of Operation Parameters dialog box for 3 Axis operations need to be modified.
52. CW-113165 CSR-19234 Toolpath For Contour Mill toolpaths generated for hole/circular pocket features, the Retract move out of the hole/pocket becomes angled when the ‘Retract between features’ is set to ‘Use Skim Plane’.
53. CW-113034 CSR-19096 Toolpath For any Mill part, if the Contour Mill operation is defined for a Curve feature with the lead in point defined at the start point, then it does not calculate correct lead out and the lead in/out overlap moves.
54. CW-113027 CSR-19099 Toolpath Error when Turning off all cutter compensation produces varying toolpaths with specific tool.
55. CW-112980 CSR-19032 Translation In Chinese Traditional language version of CAMWorks For Solid Edge, it is observed that the translation of certain VoluMill parameters is incorrect.
56. CW-112973 CSR-19042 Toolpath Rough Toolpath generation missing with 0 allowance.
57. CW-112928 CSR-19003 Toolpath Gouge check does not work with avoid areas in place.
58. CW-112879 CSR-18937 Toolpath The wrong toolpath in combination with “Look ahead” and spring passes in contour milling.
59. CW-112870 CSR-18950 VoluMill For the specific part, VoluMill toolpath for a wrapped slot feature has some moves with angle rotation greater than 180 degrees. This causes the tool to crash through the part as the machine attempts to follow the shortest path from one point to another.
60. CW-112865 CSR-18924 Toolpath Plunge Rough does not generate a correct toolpath when WIP is active.
61. CW-112840 CSR-18875 Turn For the specific programmed Turn part containing sync codes, adding a new sub spindle operation removes all existing sync codes from the CAMWorks Sync Manager.
62. CW-112802 CSR-18833 User Interface If user doesn’t want to use Indexing options and therefore sets Indexing to ‘None’ in Indexing tab of Part Set Up Parameters dialog box it is observed that the selection reverts to’ Automatic’ after closing and opening the dialog box again.
63. CW-112163 CSR-18548 Toolpath For the specific assembly, the toolpath generated with full radius comp and ramp as cut amount, directly goes to the feature depth, and then moves up.
64. CW-112121 CSR-18516 Toolpath The 2.5 Axis rest roughing toolpath issue by WIP on a part perimeter feature.
65. CW-112059 CSR-18479 Assembly In Assembly mode, the sub-spindle coordinate gets rotated when the stock geometry is changed and the toolpath is regenerated. It gets corrected only when the sub-spindle coordinate is refreshed from the part manager.
66. CWR-1995 CSR-18383 Toolpath When the 3 Axis Mill Toolpath generation method is set to ‘Advanced’ and a Z Level operation is generated to machine the mill part from the very top of the mill part within a defined contain area, the Slope options are not allowing the tool to begin machining at the top of the mill part when ‘Contact Areas only’ checkbox is unchecked.
67. CW-111783 CSR-18288 TechDB Within the customized TechDB, user has assigned a userdefined strategy for circular pocket features and assigned it as the default strategy. However, when Extract Machinable Features command is executed, the newly assigned default strategy is not assigned to circular pockets.
68. CW-111591 CSR-18116 Setup Sheet For any Centre Drill and Bore operation, the Tool ID variable from the Tool tab is not passed into Setup Sheet data.
69. CW-111568 CSR-18090 Toolpath In the attached part, wrap feature toolpath has some moves with angle rotation greater than 180 degrees which causes tool to crash through the part because machine follows the shortest path
70. CW-111010 CSR-17873 Toolpath For Turn parts, the user is getting an entry move for the Step in angle in the Turn Rough toolpath that doesn't abide by the value set in the Step In parameter. It sometimes results in tool breakage.
71. CW-110807 CSR-17701 VoluMill The cut amount is generated incorrectly in the VoluMill toolpath when the Rest machining option of "from WIP" is selected.
72. CW-110761 CSR-17757 Rebuild In the Assembly mode when any changes are done for the stock, the Stock does not update Toolpath automatically unless regeneration is performed consecutively for two times.
73. CW-110721 CSR-17737 VoluMill When 2.5 Axis VoluMill toolpath is set to Rest Machining using the "Previous Leftover", the toolpath generated is incorrect if the ‘Generate Toolpath’ command is executed from Mill Setup level.
74. CW-110575 CSR-17628 Operation For the specific Mill-Turn part, the work co-ordinate offset defined for some setups change to sub-spindle work offset after executing full Generate Toolpath.
75. CW-110260 CSR-17493 Assembly When a Pattern Project operation is imported from a part file into an assembly, it is observed that the directions of the flow line curve sketches are incorrect.
76. CW-110090 CSR-17429 Toolpath For a specific Mill part, specifying a Contain Area to reduce the number of holes to be machined excessively increases the machining cycle time.
77. CW-110074 CSR-17413 Toolpath Multiple Spring passes causes Gouge Check alarm when generating toolpath
78. CW-110067 CSR-17000 System When CAMWorks For Solid Edge 2020 SP1 is loaded as an Add-in within the Solid Edge 2020 MP11 version, then the Solid Edge application crashes. The crash is observed occasionally.
79. CW-109863 CSR-17222 Toolpath For the specific mill part, incorrect Contour Mill toolpath is generated when Leadin and leadout is applied. This happens when the gauge check option is enabled under the NC tab and the entry method is set to ‘Spiral’.
80. CW-109646 CSR-17067 Post In Turn mode, the Edit Toolpath functionality doesn’t support Z Moves though the XZ section. Consequently, these moves don’t get posted in the NC code resulting in errors.
81. CW-109031 CSR-16546 Toolpath For the specific Turn part, CAMWorks For Solid Edge fails to generate toolpath for the Groove Finish operation generated for Face Groove feature when a user-defined turn insert is used.
82. CW-107802 CSR-16440 Mill-Turn In Mill-Turn mode, the Sub-Spindle Work Coordinate Offsets for the Mill Part Setups don’t get updated correctly.
83. CW-107801 CSR-16448 Toolpath For the specific Turn part, on toolpath generation, one of its Bore Finish toolpaths changes its retract move which leads to overcutting (Gouge) of the part during rapid move. This happens though “Gouge Check” option is checked.
84. CW-107505 CSR-16258 Toolpath In the attached part, drill toolpath generated for a group hole feature does not follow the selected optimization method inside to Out
85. CW-107036 CSR-16150 Toolpath When toolpath is set to “Without Compensation”, inconsistent chamfer toolpath is observed for identical features in a feature group.
86. CW-107017 CSR-16108 Toolpath The wrong leadin move is observed for the Contour Mill toolpath during the spring pass move. This happens when the gauge check option under NC tab is enabled with the Toolpath Center set to ‘without compensation’.
87. CW-106919 CSR-15960 Toolpath Contain Area corrupts the ramp toolpath depth cut increments
88. CW-106808 CSR-15887 Toolpath For the specific Mill part, the Contour Mill toolpath with Chamfer machining generated for the Curve feature. If the leadin type is set to ‘Arc’ and a negative leadin overlap is applied, it is observed that the negative overlap doesn't work.
89. CW-106645 CSR-15852 Toolpath For hole features, the Rest Machining and WIP generates Irregular toolpath after drill tool size is altered.
90. CW-106229 CSR-15718 Toolpath In an Assembly, for the Contour mill toolpath the Chamfer depth is wrong when the Avoid Area is active.
91. CW-105478 CSR-15458 VoluMill For the specific Mill part, the VoluMill Pre-Drilled Hole option fails to populate the drilling instance for all the instances of a feature group.
92. CW-104591 CSR-15003 Toolpath In Mill mode, for irregular corner slot features, the presence of an additional air segment in the feature definition causes the corresponding offset Roughing toolpath to incompletely machine the cavity area.
93. CW-104497 CSR-14968 Feature When creating an open contour feature, the direction of cut is not in the correct direction when generated by surfaces. Even after changing it by 'Flip direction to cut' from the feature edit window and save, it returns to the earlier condition.
94. CW-104296 CSR-14866 TechDB In the TechDB application, the error messages need to be improved when the TechDB application couldn’t connect to the TechDB database file.
95. CW-104170 CSR-14803 Simulation For the specific Mill part, the target part displayed in Simulation mode is incorrect. This results in incorrect Comparison.
96. CW-102642 CSR-14080 CSR-16780 CSR-17650 Feed Speed When F/S parameter is defined using a Tool, then an option to adjust the feed rate if RPM is changed due to Max RPM limit must be made available.
97. CW-102507 CSR-14107 VoluMill If Rest machining option is selected then 2.5 axis VoluMill toolpath, then it does not follow the defined depth of cut for machining.
98. CW-102419 CSR-14056 Feature When a 2.5 Axis Mill Curve feature is created using ‘Auto select edges for chamfering‘ option (for both planar and non-planar edges) and the 'Flip direction to cut' option is selected, the material direction for the curve feature doesn’t get updated on clicking the OK button.
99. CW-102286 CSR-13919 Turn When any Retract option is set (Preset Position/Auto/Retract Point then Reset) under NC tab for a Bore Rough operation generated for the specific Turn part, it crashes the part.
100. CW-100008 CSR-13142 Toolpath For the specific Mill part, if a Contain Area has been defined, then the Ramp moves of the Contour Mill toolpath with Ramp get generated correctly but don’tfollow the assigned depth within the contain area.
101. CW-98497 CSR-12450 Operation For Turn and Drill operations, when the Spindle mode is "SMM" and the feed type is "FPR", it is observed that the machining time displayed for the Feed move in Statistics tab is a large incorrect value.
102. CW-98103 CSR-12273 CSR-14446 CSR-17648 Toolpath Toolpath generated for taper feature does not consider the taper angle and generates toolpath in the opposite angle direction.
103. CW-98084 CSR-12274 ToolpathFor the specific Mill part, the Contour mill toolpath generated for a curve feature seems to correct but when posted it generates some unwanted arc moves that gouges the part.
