CIMCO Edit 2023 (23.01.33)

CIMCO Edit 2023.01.32

Fix: Fixed feedrate in Haas Turning G70.
Fix: A freeze in the simulation collision detection system.
Fix: An issue where closing the simulation window while parsing NC lines would not reset the progress bar.
Fix: Fixed ignoring tool change sequence on tool command in some cases. (S20054)
Fix: Unscaled start position when using tool change position as a start position.
New: Now possible to manually edit axis slider values.
New: Tool Setup: It is now possible to add filepaths for 3D tools on either .stl or .ToolData formats.
New: Now supports angled head machines.
New: Spindle geometries that rotates with the tool spindle can now be defined.
Fix: An issue where it would sometimes use machines from a V2022 installation.

CIMCO Edit 2023.01.31

Fix: An issue where collision detection with models defined in inches would sometimes not work properly.
Fix: Allowed 4 digits after decimal point for "Cutter Allowance" and "Collision Step Size" values. (S19961)
Fix: An issue where changing between milling and turning controls while backplot was active, did not update view modes.
Fix: Feedrate and spindle speed information text now has trailing zeros trimmed.
Fix: Issues with Siemens Turning reverse post drilling cycles in mill-turn mode.
New: Optimized Editor start-up time.
Fix: Fixed pecking retract distance in cycle 203 for Heidenhain reverse post.
Fix: Fixed cycle 83 in Siemens turning reverse post.
New: Main stop condition button can now be used to toggle all collision and limit errors on/off.
New: Collision detection now works in backplot mode if you have machine simulation license.
New: Now doesn't detect collision with invisible models.
Fix: Fanuc milling G66 issue.
Fix: An issue where toggling machine sim back and forth could make strange transformations to base models.
New: Added "Subprogram folder" simulation setting.
Fix: Fixed Heidenhain cycle 209.
Fix: Mirror issue for turning toolpath. (S12579)

CIMCO Edit 2023.01.30

New: Now shows stopping condition reason when stopping.
Fix: An issue where going to Holder/Stock collisions would sometimes go to a collision-free part of the toolpath element.
Fix: Tool/Stock collision highlighting.
Fix: Fixed reverse post Siemens milling cycles 83/84. (S19871)
Fix: Fixed Heidenhain default work offset behavior.
Fix: Fixed rectangular stock origin type scanning. Fixed custom tool scanning issue.
Fix: Fixed incorrect lathe threading simulation. (S19802)
Fix: G100 support in Brother reverse post. (S19816)
