Camnetics GearTeq 2010.18.32.317 (x86/x64)
Camnetics GearTeq 2010.18.32.317 (x86/x64) | 36.20 MB
GearTeq™ provides the designer with advanced tools for creating solid models of drive components and assemblies. GearTeq™ is a new program that offers advanced features. Work with multiple parts and assemblies and more…GearTeq is a add-on for SolidWorks and AutoDesk Inventor.
Some of GearTeq's enhanced features:
Work on Multiple types of components in the same assembly
See any changes to the geometry instantly on the display window
Multiple gears created as a single SolidWorks part
Internal splines can be used as a bore on all components
Modifying CAD parts created by GearTeq is very easy
Automatically create assemblies in SolidWorks with proper mating
Ten standard planetary gear systems are available with a few clicks
High ratio cycloid set (a single eccentrically mounted planet and a fixed internal gear)
On screen animations to help you visualize the working gears
Warnings when GearTeq detects something in your design that may not be proper
3D wire frame with some surface shading
Create XY outputs of the involute points in Excel and text files
Create data sheets using Excel or text files
A description of each parameter is in the lower section of the property grid
Involute profile modification using linear or parabolic deviation for spur and helical gears
Automatic balance of addendum modification for spur and helical gears
Create additional tooth profiles that take into consideration the shrinkage of molded plastic gear teeth
Deviation chart for DIN splines, hub space width/shaft tooth thickness fit
An easy to use sizing for standard spur gears
Programmed on a platform that will allow greater enhancements in the future
This release is compiled for x32 operating systems (it will run fine on your new x64 machine) but it will be available as an x64 program at a later date. To start GearTeq use the Window> Start All Programs's menu.
The first time you start GearTeq, go to Help>GearTeq Quick Start Guide to view a PDF for concise instructions on getting started.
Please feel free to contact us with your comments, likes/dislikes and any problems you might encounter. We want your feedback!
While GearTeq as no intention of replacing your CAD system it does want to provide some of the functionality you have become accustomed to. With CAD like features, you can view components with drag, rotate and multiple zooms options. You can also drive the components for immediate animation!
Home page - http://www.camnetics.com/
